Custom Spline Generator

This is a tool I made for myself to make complex spline meshes with few clicks.

[It isn't meant for production, it has some known issues, use at your own risk]

Tool for UE4 made completely on blueprints.

Spline blueprint fully configurable through the details panel

- Blueprint organised and commented.

- 2 meshes setup on each side (plug, socket, connector, etc)

- 1 extra middlemesh (middle knots, connections, details, etc)

- smooth Loop mode

- collision switch for performance

- Debug mode (material, Splinepoints, upVector)

- Static meshes, Main spline and per splinepoint controls (torsion, scale, swap spline mesh segment, rotation, etc)

Simple and complex base materials with userfriendly parameters (including texture maps, tesselation, etc)

- automatic material stretching using spline length

- simple twist error fix.

Known Issues and workarounds:

- It's meant to be used on a plane, twist error fix parameter is a workaround and can break the tiling.

- use rotation on splinepoints ONLY as a manual fix of the twist error, it will break material tiling. To add roll use the parameter on the details panel.

- although it's possible to add and delete splinepoints, it won't keep the parameters on it's place.

-when loop is enable adjust manually the loop stretching on the material panel.
